Fieldking UP Model Disc Harrow

Fieldking UP Model Disc Harrow Description

• For breaking the roots.

• High quality steel discs.

• It can be used in light and medium soil.

• To air the soil and to eliminate the weeds.

• Tillage depth of the harrow is 127~178 mm.

• Maintenance is easy but needs to be scheduled.

• Easily transportable – as it gets easily attached and mounted.

• Used in open field workings for the superficial ploughing, for the shattering of clods, preparation of soil for sowing, burial of organic substances & remains.

• It has low purchasing and utilization costs both for its wide working width, and for its high speed (from 7 to 15 km/hour).

Technical Specifications

Model

FKUPMH-12

FKUPMH-14

Gang Bolt / Axle

'C' Class Heavy Duty ERW Tube

No. of Disc

12

14

Type of Disc

Plain Disc

Disc Diameter (mm / inch)

560 x 4 T (22")

Tillage Width (mm / inch Approx)

1420/56"

1635/64"

Distance  Between Discs (mm / inch)

228/9"

Bearing Hubs

4

Weight (kg / lbs Approx)

390/860

420/926

Tractor Power (HP)

40-45

45-50



Similar Tractor Implements
