Technical Specification | |
Cutter-bar (mm) | |
Effective width | 2115 |
Threshing System | |
Drum Diameter | Tangential Axial Flow (TAF) |
Drum Width | 830 |
Speed Range | 600 |
Grain tank | |
Capacity (L) | 1200 |
Engine | |
Manufacturer | TATA |
Emission Class | BSIII |
Model | 497 TCIC Turbo Intercooler |
Cylinders/Displaements | 4 , 3713 CC, Inter Cooler |
Maximum power | 76 |
Rated Engine Speed | 2200 |
Fuel Tank Capacity | 100 |
Overall Dimension | |
Length (with front attachment ) | 7185 |
Length (without attachment) | 5410 |
Width | 2832 |
Transport width | 2015 |
Tyre Sizes | |
Front | 13.9 x 28 |
Rear | 7.50 x 16 |
Weights | |
Machine Weight | 5000 |
Crop Cleaning | |
Cleaning sieve area (sq.mt.) | 2.34 |
Fan Speed | 1200-1500 |
*The information and features are as on the date those are shared by Claas or Budni report and for the current features and variants the customer requires to visit the nearest Claas dealer. Prices shows above are Ex.Showroom price. All Prices are indicative it may be vary as per your buying condition and location. For Exact price kindly send On Road Price Request or visit the nearest Claas Tractor dealer.
